Haskel 86981 Hydrogen Booster

Haskel 86981 Hydrogen Gas BoosterNOTE: this is a version of the model AG-152 Gas Booster modified for HYDROGEN service.Features & Benefits:Reliable, easy to maintain, compact and robustNo heat, flame or spark riskInfinitely variable cycling speed and outputPneumatic driven units do not require electrical connectionsEasy to apply automatic controlsNo limit or adverse affect to continuous stop/start applicationsSeal systems designed for long working lifeNo air line lubricator requiredHydrocarbon free – separation between air and gas sectionsBuilt-in cooling (most models)Suitable for most gasesAbility to stall at any predetermined pressure and hold the fixed pressure without consuming power or generating heatTechnical Data:Ratio: 152:1Min GAS supply pressure: 250 psiMax GAS supply pressure: 20,000 psiMax rated GAS outlet pressure: 20,000 psiStatic outlet stall pressure formula: 150 Pa (Pa = airdrive pressure)Min AIR drive pressure: 20 psiMax AIR drive pressure: 150 psigSample Performance Characteristics:Boost 1.3 SCFM Gas from 2,000 psi to 13,000 psi while using 20 SCFM Air @ 90 psig supply pressureBoost 2.3 SCFM Gas from 3,500 psi to 13,000 psi while using 20 SCFM Air @ 90 psig supply pressureBoost 3 SCFM Gas from 5,000 psi to 13,000 psi while using 20 SCFM Air @ 90 psig supply pressureBoost 3.6 SCFM Gas from 6,500 psi to 13,000 psi while using 20 SCFM Air @ 90 psig supply pressurePhysical Characteristics:Unit weight: 27 lbs.Displacement / cycle: 1.2 cu. in.Max cycles: 60/min.GAS inlet/outlet connections: Interchangeable 3/8″ SAE or 1/4″ HPAIR drive inlet port: 1/2″ FNPTHaskel 86981 Hydrogen Gas Booster Repair kit information:Gas section seal kit P/N: 87448, 87122Air drive section seal kit P/N: 51545-2Air valve seal kit P/N: 17329Check valves seal kit P/N: 17325Distance piece kit P/N: N/AOptional tools: 28584 (Sleeve removal tool); 16675 (Wrench for gas booster check valve seats); 17245 (Wrench for gas booster piston nut)Notes: P/N 87448 is Gas Section Seal Kit; P/N 87122 is Gas Piston Seal Kit.Optional Modifications:C or C-8: Air filter, regulator with gauge, and manual start/stop17860: Electrical stroke counter25721: Mechanical stroke counter29376: Three-way cycling spool29702: Single-stroke modification50341: Low permeability seals for CO2 gas service51050: Extreme service cycling modification54827: Level II cleaning and certification of gas sections56611: Vent purge with 15 psi relief (single end models)56611-2: Vent purge with 15 psi relief57875: Panel with regulator for mounting remote APS59888: Cycle timer80862: Viton air drive seals82500: ATEX modification86337: Extended life air drive seals To add any modifications to this Gas Booster or for assistance in selecting the right gas booster for your application, please contact our Sales Department for assistance.   Product Catalog: Gas Booster Catalog  Installation Documents: SKIS-001  SKIS-002  SKIS-005  SKIS-006  SKIS-008  SKIS-014
